Band Saw Cutting Machine
Description
GB4240 Band Saw Machine Main Features
- Stable gantry double column
- Quickly raise the saw frame and retract the blade
- Hydraulic clamping /Hydraulic vise
- Controllable stepless speed regulation
- High-power worm gear transmission
- High-power worm gear reducer
- Adjustable saw band guide device
- Flexible switch control/ Convenient control system
- High rigidity bimetallic band saw blade
- International standards
- Smooth blade synchronous wheel
The standard attachment parts of machine
| No. | Name | Quantity |
| 1 | Saw blade | 1piece |
| 2 | Wire brush | 1 piece |
| 3 | A set of tools | 1 set |
| 4 | driving belt | 1piece |
| 5 | Manual | 1copy |
Technical Specification
| Specifications | GB4240 |
| Max. cutting(mm) | 400Lx400W×400H |
| Saw blade speed(m/min) | 27/45/69 |
| Saw blade size(mm) | 41×1.3×5000 |
| Working clamping mode | Hydraulic vice |
| Main transmission structure | Worm gear transmission |
| Band saw blade tensioning method | Manual |
| Cleaning | Wire brush & flood coolant |
| Main motor(kw) | 4 |
| Hydraulic motor(kw) | 1.1 |
| Cooling motor power(kw) | 0.09 |
| Dimensions(mm) | 2400×1300×1800 |
| Weight(kg) | 1400 |
